K-style handset magnetic cradle for campus telephone C10

Short Description:

This cradle is mainly designed for K-style handset with cheap price. In function, we could add normally open or normally closed reed switch on it.

With auto mechanical arms, auto sorting machines, auto painting machines and so on automatic machines, We have improved the daily capacity to most and reduced the cost from every points.

Send email to us

Product Detail

Product Tags

Product Introduction

ABS material cradle for industrial telephone used in campus or public machines.

Features

1. The cradle is made of engineer UL approved Chimei ABS material which has vandal proof features.
2. With high sensitivity reed switch, continuity and reliability.
3. Color is optional
4. Range：Suitable for A05 handset.

Application

It is mainly for access control system, industrial telephone,vending machine, security system and some other public facilities.

Parameters

Item	Technical data
Service Life	>500,000
Protection Degree	IP65
Operate temperature	-30～+65℃
Relative humidity	30%-90%RH
Storage temperature	-40～+85℃
Relative humidity	20%～95%
Atmospheric pressure	60-106Kpa
