VOIP-SIP-IP Dispatcher Display intercom phone desktop Telephone for self service stores

Short Description:

The stainless steel desktop intercom is sturdy and hard to damage. Even if it falls from a height of 2 meters, there will be no problem. You can place the intercom on the table or use a rubber handle to secure it to the table to prevent slipping.Sometime it can connect the voip intercom wall mounted to talk with others.

With a professional R&D team in industrial telecommunication solution filed since 2005 Year, Each Intercom Telephone have been passed the FCC,CE international certificates.

Your first-choice provider of innovative communication solutions and competitive products for the Desktop intercom communication.

Send email to us

Product Detail

Product Tags

Product Introduction

Analog version of the desktop intercom system
To build a simulated desktop intercom system, you need to purchase a simulated version of the desktop intercom and analog version of the phone or intercom. The most important thing is to need a PBX. Connect all analog terminals to the simulated PBX.
Voip version of the desktop intercom system
Using Voip network to build an intercom system is currently the most advanced communication system. We recommend you the phone system which we built with IP PBX technology, using Sip server. The desktop intercom system using sip server, with powerful media functions, queue, monitoring, scheduling and other functions.
Several versions are available, color customized，with or without LCD display,with keypad, without keypad and on request with additional function buttons.
Telephone parts is produced by self-made , every parts like keypad could be customized.

Features

1.Support 2 lines SIP, SIP 2.0 (RFC3261).
2.With 7-inch touch screen, virtual keyboard
3.Audio Codes:G.729、G.723、G.711、G.722、G.726,etc.
4.304 stainless steel material shell, high mechanical strength and strong impact resistance.
5.Gooseneck Mike, free hands when talking.
6.Weather proof protection to IP65.
7.Register to the server and make a call based on the server's dialing rules. Press the call button to pop up the dialing
interface, enter the number you want to dial and press the dial button to make a call.
8.Answer the call: When there is an incoming call, press the call button to answer the call.
9.When the call ends, press the call button again to end the call or the busy tone automatically hangs up.
10.Self-made telephone spare part available.
11.CE, FCC, RoHS, ISO9001 compliant.

Application

This Master station is applicable to the main control room of the command and dispatch system such as control room and dispatching room.

Parameters

Item	Technical data
Protocol	SIP2.0(RFC-3261)
Audio Amplifier	2.4W
Volume Control	Adjustable
Support	RTP
Codec	G.729、G.723、G.711、G.722、G.726
Power Supply	12V (±15%) / 1A DC or PoE
LAN	10/100BASE-TX s Auto-MDIX, RJ-45
WAN	10/100BASE-TX s Auto-MDIX, RJ-45
Installation	Desktop
Weight	3.0KG
